Description
This Premium Heavy Duty Lithium-Ion Battery Storage Cabinet is designed for the safe storage and charging of lithium-ion batteries. Fabricated from 1.5mm thick cold-pressed sheet steel and finished in anti-acid epoxy powder paint, this cabinet is built to withstand harsh environments while providing secure storage.
The cabinet is fitted with 4 perforated shelves and features a FirePro suppression system, which is an automatic fire detection and extinguishing generator triggered by a Thermo Activator bulb. This provides an additional layer of safety to reduce potential fire incidents during charging.
Charging Features
Equipped with 24 power sockets (6 power sockets per shelf) for efficient battery charging, the cabinet includes charging sockets rated at 16A, featuring a 32A circuit breaker and an illuminated on/off safety switch. The control panel allows for manual control over the FirePro system.
Please note: This cabinet will be delivered stood upright. If it arrives laying down, please reject it.
Features:
- 24 power sockets for battery charging (6 x power sockets per shelf)
- Automatic hydraulic closing door system operates at high temperatures for safety
- Anti-spark hinges to prevent ignition
- Integrated ventilation system for heat dissipation
- 5G6mm2 cable section with a 4-pole plug
- FPC-2V2 control panel for system management
- Sounder beacon for alerts
- Smoke and heat sensors for heightened safety
Dimensions & Specifications
| Specification |
Measurement |
| External Dimensions |
1200mm (L) x 600mm (W) x 1950mm (H) |
| Empty Weight |
350kg |
| Fire Resistance Certification |
Certified 90-minute fire resistance to EN 14470-1 TYPE 90 |
| LPCB Certification |
Certified to EN 12094-1 and EN 54-2 and 4 |
Technical Specifications
- Material: 1.5mm thick cold-pressed sheet steel
- Finish: Anti-acid epoxy powder paint
- Control Panel: FPC-2V2 with manual control capability
- Power Supply: 16A rated charging sockets with 32A circuit breaker
FAQ
What is the fire resistance rating of the cabinet?
The cabinet has a certified 90-minute fire resistance rating according to EN 14470-1 TYPE 90.
How many batteries can I charge at once?
The cabinet features 24 power sockets, allowing for simultaneous charging of multiple batteries.
